Strobe Panel LEDs

LED Type: 5050 0.5W RGB 3in1 LEDs
LED Count: 480
LED Colors: RGB
LED Segments: 8 (2 x 4)

Strobe Tube LEDs

LED Type: 3535 5W 6500K LEDs
LED Count: 144
LED Colors: Cool-White
LED Segments: 4

Movement

Resolution: 8-16 Bit
Position Feedback: yes
Tilt (Degrees): 185°

Control

Control Modes: 7CH / 14CH / 15CH / 42CH / 43CH Display:
Illuminated graphic LCD
Protocol: USITT DMX-512, RDM
RDM: Bidirectional communication
Wireless DMX: 2.4 GHz W-DMXTM (optional)
Cooling: Temperature controlled, overheating protection

Effects

Dimmer: 0-100% electronic
Shutter: electronic, max. 20 Hz
Internal Effects: LED Macro Effects

Connectors

Signal connection: Seetronic IP65 XLR 5-Pin or 3-Pin In/Out
Power Input: Seetronic powerCON TRUE1 In/Out

Operating Condtions

Mains voltage: 100-240V AC / 50-60Hz
Power: 1000W
Maximum ambient temperature: -30°C / 86°F, 50°C / 122°
F Operating Position: any

Mounting Options

Standing: Rubber feet
Hanging: Omega-Bracket
Safety wire attachment: foldout eyelets

Shipping

Single fixture: cardboard (inner and outer cartons)
Tourpack: 4-way Flight Case
Housing Colors
Standard colors: black

Dimensions

Length: 482 mm / 18.9 in
Width: 178 mm / 9.0 in
Height (head horizontal): 243 mm / 9.5 in
Weight
N.W: 10 kg / N.W: 22 lbs
