Product Description

• Better discussion control

• Controls up to 50 Discussion units

• Built-in audio recorder and amplifier

• Audio interfaces for connecting external audio equipment

• The CCS700 Ultro Discussion System is suitable for use in meetings and conference venues with a limited number of participants

• The Control Unit (CCSE-CURA) is the heart of the CCS700 Ultro Discussion System and supplies the power for all delegate and chairman units in the system

• The unit also controls the chairman and delegate unit microphones,as well as providing interfaces for external audio equipment

• The CCS700 discussion system is a plug and play solution for the audio conference requirements

• Functions

• Discussion Control

• The CCSE-CURA (CURA) supports almost any kind of small or medium meeting

• For business discussions and small conferences,two to six microphones can be active simultaneously,with the chairman always having speaker priority

• The active microphone selection knob on the rear panel can be used to select the number of active participants

• Unused microphones are switched off automatically after 60 seconds if delegates forget to switch off their units

• Supplies Power For Up To 50 Discussion Units

• The CURA has two trunk outputs for the loop through connection of discussion units

• It is possible to connect a maximum of 25 discussion units to each trunk output in open loop configuration

• Maximum trunk length supported by CURA is 100 meters in open loop configuration

• For closed loop configuration with 50 discussion units the loop length can be extended up to 200 meters

• A maximum of 50 discussion units can be connected to a CURA

• Recorder And Amplifier

• The CURA has a built-in recorder,the user needs to plug in either USB pen drive or a SD card,to record the meeting,which can be used to playback the recorded Meeting

• The Controller is also equipped with a 30 Watts power amplifier,by which the user can connect additional loudspeakers for sound reinforcement

• Audio Interfaces

• The CURA can be interfaced with different types of device like a sound reinforcement system, external microphones and an external music player

• The headphones output on the front of the CURA can be used by a secretary for taking the minutes of the meeting,the headphones output also has a volume control knob to adjust the volume of the headphones

• To support external participants (during town-council meetings,for example), extra microphones in any style (wired, wireless, hand-held or podium) can be connected to the system through mic inputs

• Controls And Indicators

• Audio record and playback module for recording ongoing conference in USB pen drive/SD card

• Volume control for Mic 1 input

• Volume control for Mic 2 / Aux input

• Headphones input and volume control

• Master volume control

• Slide switch for limiter On/Off

• Speaker output - 100 V/8/4 Ohm

• Slide switch to enable or disable the priority tone for chairman units

• Control knob for selecting active participants

• Interconnections

• Trunk input and output 8-pin DIN connectors for loop through connection

• Microphone input with XLR connector

• Configurable Mic or Aux input with 6.5mm phono jack

• Cinch connectors for connecting to external PA system and Feedback suppressor or Equalizer

• Earth connection screw

• Mains socket

Product Specification

Brand	Bosch
Product Type	Controller Unit
Product Model	CCSE-CURA-IN
Electrical
Mains Voltage	220 - 230 VAC, 50 Hz
DC Supply To Contribution Units	24 V ± 1V DC
THD At Rated Output	<1%
SNR	>50 dB at rated output (unweighted filter)
Inputs
Mic Input Sensitivity	1 mV ( 1/-3 dB)
Aux Input Sensitivity	100 mV ( 1/-3 dB)
Frequency Response	200 Hz to 12 kHz ( ±3 dB)
Input Impedance For Aux	100 kohm for Single ended
PA Output
Rated Output Impedance	100 ohm
SNR	>50 dB at rated output (unweighted filter)
Amplifier Performance
Maximum Output Power	45 W
Rated Output Power	30 W
Frequency Response	80 Hz to 18 kHz ( 1/- 3 dB @10 dB ref at rated Output)
Loudspeaker Output	1 x
Connector	Phoenix
Direct Output	100 V, 8/4 ohm
Distortion	<1% at rated power, 1 kHz
Environmental
